Crane hoist: Types of cranes hoists, gantry hoist and overhead hoist

04 Jan, 2017

Crane hoist and crane system for sale with lifting capacity from 250kg, 1000kg, to 100 ton +, which can be used indoor or outdoor places, such as, home, building site, construction sites, warehouse, industrial factories, workstation, and together with overhead crane, gantry crane, and jib crane, etc., to complete various types of material handling works.2lxHenan Dongqi Machinery Co., Ltd

2lxHenan Dongqi Machinery Co., Ltd

Hoist video: 10 ton crane hoist testing video2lxHenan Dongqi Machinery Co., Ltd

How do Crane Hoists Work

Crane hoists are machines that are able to lift and carry heavy objects and loads from one place to another place, by using a drum or lift wheel that has either a rope or chain wrapped around it. Crane hoists can be classified into many different types according the way of operation, such as manual crane hoist, electronical crane hoist, or pneumatic crane hoist, etc. There are basically two unique things that distinguish a crane hoist from the many other types of lifting machines out there: the lifting medium and the type of power used. They adopt either wire, rope, or chains to lift and their power source is either an electric engine or an air motor.2lxHenan Dongqi Machinery Co., Ltd

Types of crane hoists

Construction crane hoist

Among types of crane hoists, the construction crane hoist is one type of hoist used for construction of large buildings, known as man-lift and buck hoist. The construction crane hoist usually consists of either one or two cages which travel up and down along a tower of stacked sections. Each section of mast is roughly 25 feet high, and it is important that they be added at these intervals in order to provide stability. Using a system of rack and pinion motorization, the cages are able to travel along the mast sections at various speeds.2lxHenan Dongqi Machinery Co., Ltd

Mining crane hoist

Mining crane hoist is a type of electric hoist, which can be used in underground mines. The mining crane hoist can be operated by using either man, water, or animal power and mostly electricity and are used to raise and lower conveyances into the shaft Electric hoist is the most frequently used hoist. Three different types of crane may be used for this type of operation: drum hoists, friction hoists, and multi-rope cranes.2lxHenan Dongqi Machinery Co., Ltd

Chain crane hoist and rope crane hoist

Most crane hoists in use today use are either chain or rope in their design. Those that use chains typically have a lever that actuates the hoist. There is a commonly used handheld model known as the ratchet lever hoist that is operated manually. One of the advantages of using this type is that they can be used in any orientation, whether pulling, lifting, or binding. When choosing between either rope or chain, remember that rope is more light weight but is limited by the drum diameter. Chains on the other hand are much larger and heavier.2lxHenan Dongqi Machinery Co., Ltd

Rail crane hoist

One of the overhead hoists use rails which are located high above the ground. The overhead rail hoists are usually supported by a building or some other type of structure. The main advantage of the rail overhead hoist is that they are safely out of the way and do not cause an obstruction in the workplace. When speed and portability is an important issue, the truck mounted crane is the perfect choice. It can travel along the public roads so it can quickly move from one location to the next.2lxHenan Dongqi Machinery Co., Ltd

Types of crane hoist offering of Dongqi Hoist and Crane

  • Double speed crane hoist 2lxHenan Dongqi Machinery Co., Ltd

    MD double speed crane hoist for sale 2lxHenan Dongqi Machinery Co., Ltd
    crane hoist specifications 2lxHenan Dongqi Machinery Co., Ltd
    Product Type: MD1 2lxHenan Dongqi Machinery Co., Ltd
    Lifting Capacity:0.5~32t 2lxHenan Dongqi Machinery Co., Ltd
    Lifting Height:6~50m 2lxHenan Dongqi Machinery Co., Ltd
    Working Class: M3,M4 2lxHenan Dongqi Machinery Co., Ltd
    Ambient Temperature: -25~40℃2lxHenan Dongqi Machinery Co., Ltd

  • single speed wire rope crane hoist2lxHenan Dongqi Machinery Co., Ltd

    CD single speed crane hoist for sale 2lxHenan Dongqi Machinery Co., Ltd
    crane hoist specifications 2lxHenan Dongqi Machinery Co., Ltd
    Product Type CD1 2lxHenan Dongqi Machinery Co., Ltd
    Lifting Capacity: 0.5~32t 2lxHenan Dongqi Machinery Co., Ltd
    Lifting Height: 6~50m2lxHenan Dongqi Machinery Co., Ltd
    Working Class: M3,M4 2lxHenan Dongqi Machinery Co., Ltd
    Ambient Temperature: -25~40℃2lxHenan Dongqi Machinery Co., Ltd

  • variable-speed-hoist.jpgVariable speed crane hoist for sale 2lxHenan Dongqi Machinery Co., Ltd
    crane hoist specifications 2lxHenan Dongqi Machinery Co., Ltd
    Product Type: MD1 2lxHenan Dongqi Machinery Co., Ltd
    Lifting Capacity: 0.5~32t 2lxHenan Dongqi Machinery Co., Ltd
    Lifting Height: 6~50m 2lxHenan Dongqi Machinery Co., Ltd
    Working Class: M3,M4 2lxHenan Dongqi Machinery Co., Ltd
    Ambient Temperature: -25~40℃2lxHenan Dongqi Machinery Co., Ltd

  • electric-chain-hoist-l.jpg2lxHenan Dongqi Machinery Co., Ltd

    Electric chain hoist for sale 2lxHenan Dongqi Machinery Co., Ltd
    crane hoist specifications 2lxHenan Dongqi Machinery Co., Ltd
    Product Type DHT,WBH 2lxHenan Dongqi Machinery Co., Ltd
    Lifting Capacity: 0.5t~35t 2lxHenan Dongqi Machinery Co., Ltd
    Lifting Height: 3~50m2lxHenan Dongqi Machinery Co., Ltd
    Working Class: M3,M4 2lxHenan Dongqi Machinery Co., Ltd
    Ambient Temperature: -25~40℃
  •  Rope eletric hoist for sale Rope eletric crane hoist for sale 2lxHenan Dongqi Machinery Co., Ltd
    Electric crane hoist specifications 2lxHenan Dongqi Machinery Co., Ltd
    Product Type BCD 2lxHenan Dongqi Machinery Co., Ltd
    Lifting Capacity: 0.5~16t 2lxHenan Dongqi Machinery Co., Ltd
    Lifting Height: 6~18m2lxHenan Dongqi Machinery Co., Ltd
    Working Class: M3 2lxHenan Dongqi Machinery Co., Ltd
    Ambient Temperature: -25~40
  • nd-electric-hoist-l.jpg European electric crane hoist for sale 2lxHenan Dongqi Machinery Co., Ltd
    Electric crane hoist specifications 2lxHenan Dongqi Machinery Co., Ltd
    Product Type ND 2lxHenan Dongqi Machinery Co., Ltd
    Lifting Capacity: 1~80t 2lxHenan Dongqi Machinery Co., Ltd
    Lifting Height: 6~50m2lxHenan Dongqi Machinery Co., Ltd
    Working Class: M5, M6 2lxHenan Dongqi Machinery Co., Ltd
    Ambient Temperature: -20~40℃
  • Explosion-proof-electric-hoist-l.jpg2lxHenan Dongqi Machinery Co., Ltd

    Explosion proof rope eletric crane hoist for sale 2lxHenan Dongqi Machinery Co., Ltd
    Electric crane hoist specifications 2lxHenan Dongqi Machinery Co., Ltd
    Product Type; BCD 2lxHenan Dongqi Machinery Co., Ltd
    Lifting Capacity: 0.5~16t 2lxHenan Dongqi Machinery Co., Ltd
    Lifting Height: 6~18m2lxHenan Dongqi Machinery Co., Ltd
    Working Class: M3 2lxHenan Dongqi Machinery Co., Ltd
    Ambient Temperature: -25~40℃2lxHenan Dongqi Machinery Co., Ltd

  • metallurgical-electric-hoist-l.jpg2lxHenan Dongqi Machinery Co., Ltd

    Metallurgical rope electric crane hoist for sale 2lxHenan Dongqi Machinery Co., Ltd
    Electric crane hoist specifications 2lxHenan Dongqi Machinery Co., Ltd
    Product Type; YH 2lxHenan Dongqi Machinery Co., Ltd
    Lifting Capacity: 1~20t 2lxHenan Dongqi Machinery Co., Ltd
    Lifting Height: 6~18m2lxHenan Dongqi Machinery Co., Ltd
    Working Class: M3 2lxHenan Dongqi Machinery Co., Ltd
    Ambient Temperature: -25~40℃2lxHenan Dongqi Machinery Co., Ltd

  • Low headroom eletric hoist for sale2lxHenan Dongqi Machinery Co., Ltd

    Low headroom eletric crane hoist for sale 2lxHenan Dongqi Machinery Co., Ltd
    Normal travelling speed: 20m/min (dual speed 20/6 is optional) 2lxHenan Dongqi Machinery Co., Ltd
    crane hoist electrics cubicle including low voltage transformer 2lxHenan Dongqi Machinery Co., Ltd
    Motor protection IP54 insulation class F2lxHenan Dongqi Machinery Co., Ltd

Featured electric crane hoist

As an electric crane hoist and crane manufactuer, Donqi crane hoist and Crane is able to provide custom electric crane hoists,which can be used in various places, such as industrial workshop, workstation, warehouse, construction site, building site, home, etc. The various featured electric crane hoists, such, monorail electric crane hoist, pulley electric crane hoist, motor electric crane hoist, outdoor electric crane hoist and other types of crane hoists are at your selection.Contact us for your custom electric crane hoist now.2lxHenan Dongqi Machinery Co., Ltd

Crane hoist by Lifting Capacity:

As a professional crane hoist supplier, Dongqi Hoist and Crane is able to provide crane hoist with various tonnages, from 250kg, up to 100+ ton, etc. Custom crane hoists, such as, 250kg crane hoist, crane hoist 500kg, 500kg crane hoist, 2000 lb crane hoist, crane hoist 1000kg, crane hoist 250kg , crane hoist 2000 lb capacity ,etc.2lxHenan Dongqi Machinery Co., Ltd

CE certified crane hoist crane hoist price

Dongqi crane hoist with wide range of specifications for your selections at good price which not cheap but affordable. Dongqi crane hoist is comparable with the famous brands, such as Harrington crane hoist, Jual crane hoist, Jet crane hoist, etc. Why Dongqi crane hoist is good in quality but with affordable price? The relatively cheap crane hoist price has many reason behinds. Read more on Why Made in China hoist and crane is so cost-effective?Maybe we are not the best crane hoist supplier in the world, however, we are the top crane hoist manufacturer who can offer you CE certified crane hoist with good price.contact us for more our crane hoist certificates and crane hoist price now.2lxHenan Dongqi Machinery Co., Ltd

Voltages of crane hoist

As an international crane hoist supplier, Dongqi can provide you crane hoists which can need the voltages requirements around world,such as, 240v crane hoist, and 220v crane hoist, and 330v electirc hoist, and other customized hoists with different voltages.2lxHenan Dongqi Machinery Co., Ltd

The voltage level of the power network is divided into three categories.

  • The first category: 1 KV and above 1 KV voltage is called high pressure, such as 1 KV ,3 KV ,6 KV, 10 KV ,35 KV ,110 KV ,220 KV ,330 KV ,500 KV;
  • The second category: below 1 KV voltage is called low pressure, such as 220 V, 230 V, 380 V, 415 V, 660 V;
  • The third category: below 50 V voltage is called safe voltage, such as 12 V, 24 V, 36 V, 48 V. So the hoist power supply voltage is low pressure and control voltage is safe voltage.

Voltages offering of Dongqi crane hoists

Item Wire rope crane hoist Chain crane hoist Mini crane hoist
Figure Wire rope crane hoist Electric chain hoist Mini crane hoist
Phase Three phases Three phases or single phase Single phase
Voltage As your request As your request 220 v/230 v
Control voltage 24 V/36 V/48 V
Frequency 50 HZ or 60 HZ
Electric brand Chint (China)/ Schneider(France)/ Siemens(Germany)

More informaiton on the voltages of electirc hoist,please check article oncrane hoist voltage: 110v, 220v, 240V, 380V, which is your crane hoist voltage?2lxHenan Dongqi Machinery Co., Ltd

crane hoist operation safety lists

  1. Do not exceed the safe load limit of electrichoist.
  2. Maintain electrichoist ropes and chains lubricated.
  3. crane hoist loads up from right over the loads or it may swing when lifting if not centered.
  4. Place crane hoists in the highest part of hook area to make sure hook support is in line with hook shank directly.
  5. Lever operated crane hoist can be pulled in any direction in a straight line. However, side pulling or lifting increase wear and stress on electrichoist parts.2lxHenan Dongqi Machinery Co., Ltd
    Pushing a loaded hoistPushing a loaded hoist is safer (A). If it must be pulled, use a rope (B)
  6. To load the lower hook, place loads right in line with the hook shank to make sure load chain in a straight line from hook shank to hook shank.
  7. Stand clear of load completely.
  8. Place loads in the hook completely.
  9. Move crane hoist controls smoothly to avoid abrupt and jerky movements of loads.
  10. Make sure the sling and hoisting ropes from slacking before lifting.
  11. Keep the loads from any loose material, parts, blocking and packing before lifting.
  12. Make sure all people away from loads before lifting.

crane hoist Resources

crane hoist and crane brochure pdf
文件类型: .pdf 1. Dongqi Hoist and Crane Brochure.pdf(5.79 MB)
