Dongqi Crane provides various types of cranes with different specifications and dimensions. You can check and choose what you need.
Types of overhead cranes video presentation
Overhead crane or bridge cranes are the most widely used lifting cranes for material handling. An industrial bridge crane or overhead crane is a permanent material handling system built into a production space or warehouse and composed of a bridge beam, runways, and a trolley hoist. The purpose of this free specification offered by DQCRANES is to provide clear, concise, and accurate crane system information for bidding and procurement.
Overhead crane with two trolleys which can be used to handle heavy loads or objects. And the lifting capacity of the double trolley overhead cranes are 5 ton to 400 ton.
Double trolley overhead crane specification
Product Type: QE
Lifting Capacity: (2.5+2.5)~(200+200)t
Span Length: 10.5~35.5m
Working Class: A5, A6
Ambient Temperature -20~40℃
Crane Specifications PDF Download: QE Double Trolley Overhead Crane
Insulation overhead crane is a type of overhead crane used in hazardous environment, such as, power plants, etc.
QY Insulation Overhead Crane Specification
Lifting Capacity: 5~50t
Span Length 10.5~31.5m
Working Class A6
Ambient Temperature -25~50℃
Crane Specifications PDF Download: QY Insulation Overhead Crane
Grab bucket overhead crane is a heavy duty overhead crane with the lifting capacity of 5 ton to 25 ton, which is widely used in power station, storage, smelting workshops of steel mill, waste recycling station, etc.
QZ Grab Bucket Overhead Crane Specification
Lifting Capacity 5~25t
Span Length 10.5~34.5m
Working Class A6
Ambient Temperature -20~40℃
Crane Specifications PDF Download: QZ Grab Bucket Overhead Crane
Hook overhead crane is the most commonly used lifting equipment, which is widely used in the various factory or workshops, warehouse, stores, and other places, etc.
QD Overhead Crane With Hook Specification
Lifting Capacity 5~550t
Span Length 10.5~35.5m
Working Class A4~A7
Ambient Temperature -20~40℃
Crane Specifications PDF Download: QD Overhead Crane With Hook
Single girder electric hoist crane is a light lifting equipment which is used various environment, such as, factory, ware house, stockyard, etc.
LD Single Girder Electric Hoist Crane Specification
Lifting Capacity 1~32t
Span Length 7.5~28.5m
Working Class A3,A4
Ambient Temperature -20~40℃
Crane Specifications PDF Download: LD Single Girder Electric Hoist Crane
Electromagnetic overhead crane is a kind of lifting equipment used to handle metal materials or objects such as, ingots, structural steel, iron, scrap iron, steel and others, etc.
QC Electromagnetic Overhead Crane Specification
Lifting Capacity 5~32t
Span Length 10.5~31.5m
Working Class A5, A6
Ambient Temperature -20~40℃
Crane Specifications PDF Download: QC Electromagnetic Overhead Crane
Explosion proof single girder overhead crane is a small overhead crane with the lifting capacity of 1 ton to 20 tons which is wide used in inside factories with the detonating ability not high Ⅱ B or Ⅱ C, and flammable mixture environment with the Ignites temperature classes of T1 ~ T4 group.
LB Explosion-proof Single Girder Overhead Crane Specification
Lifting Capacity 1~20t
Span Length 7.5~28.5m
Working Class A3
Ambient Temperature -20~40℃
Crane Specifications PDF Download: LB Explosion-proof Single Girder Overhead Crane
Explosion proof bridge crane is one type of various types of explosion-proof and hazardous environment material handling equipment which is widely used in factories and sites where is not higher than the II B or II C-class, and the sites with explosive air mixture formed with inflammable gas (or steam) and air whose factory ignition temperature groups of not less than the T4 group.
QB Explosion Proof Bridge Crane Specification
Lifting Capacity 5~75t
Span Length 10.5~31.5m
Working Class A4, A5
Ambient Temperature -20~40℃
Crane Specification PDF Download: QB Explosion Proof Bridge Crane
The double girder hoist crane is very popular for high reliability and cost-effectiveness, which is applied in machinery processing workshop, warehouses, yard, plants, and other places, etc.
LH Double Girder Electric Hoist Crane Specification
Lifting Capacity 5~63t
Span Length 8m~32m
Working Class A3~A5
Ambient Temperature -20~40℃
Crane Specifications PDF Download: LH Double Girder Electric Hoist Crane
Single girder suspension overhead crane is a kind of light duty material handling equipment, with the single girder running on the suspension track. The suspension overhead crane is widely used for machine assembling, equipment installation, maintenance, etc.
LX Single Girder Suspension Crane Specification
Lifting Capacity 1~10t
Span Length 3~15m
Working Class A3
Ambient Temperature -20~40℃
Crane Specifications PDF Download: LX Single Girder Suspension Crane
Lade overhead crane is kind of overhead crane designed especially for transporting, pouring and charging hot metal in the process of smelting liquid metal, etc.
QDY Ladle Overhead Crane Specification
Lifting Capacity 5~74t
Span Length 10.5~31.5m
Working Class A7
Ambient Temperature -10~60℃
Crane Specifications PDF Download: QDY Ladle Overhead Crane
Low headroom single girder overhead crane is a light duty material handling equipment, designed for low headroom workshop application.
LDP Low Headroom Single Girder Overhead Crane Specification
Lifting Capacity 1~32t
Span Length 7.5~22.5m
Working Class A3, A4
Ambient Temperature -25~40℃
Electric hoist overhead crane is a single girder overhead crane developed by DQCANES with New Zealand advanced crane design concept and technology, confirming with international standards, i.e. DIN, FEM and ISO.
HD Electric Hoist Overhead Crane Specification
Lifting Capacity 1~30t
Span Length ≥6m
Working Class A5
Ambient Temperature -25~40℃
European double girder overhead crane is designed according to European standards, which is welcomed by European countries.
European Style Double Girder Overhead Crane Specification
Lifting Capacity 5~80t
Span Length ≥m
Working Class A5, A6
Ambient Temperature -20~40℃
European single girder underslung crane is a light duty material handling equipment which can be installed on the roof of the workplace without bracket, saving space and lowering cost.
NLX European Style Underslung Crane Specification
Lifting Capacity 1~20t
Span Length ≥ 6m
Working Class A5
Ambient Temperature -25~40℃
Types of gantry cranes video presentation
Electric trolley gantry crane is a mid –light type gantry crane, equipped with electric and crane hooks, with the obvious features of “ L” shape legs, which makes the crane more convenient for handling cargo with long length, such as, steel pipe, etc.
L Electric Trolley Gantry Crane Specification
Lifting Capacity 5~32t
Span Length 18~35m
Working Class A5, A6
Ambient Temperature -25~40℃
Crane Specifications PDF Download: L Electric Trolley Gantry Crane
Single girder gantry crane is a type of light small gantry crane with a single girder and rail travelling, which is widely used at open ground, warehouse, ports, and granite industry, cement pipe industry, open yard, container depots and shipyards, etc.
MH Single Girder Gantry Crane Specification
Lifting Capacity 1~20t
Span Length 8~30m
Working Class A3, A4
Ambient Temperature -25~40℃
Crane Specifications PDF Download: MH Single Girder Gantry Crane
Double girder gantry crane is heavy gantry crane with double girders, which is widely used for general purpose, which is widely is usually used to open warehouse or along rail for general material handling and lifting work, such as, freight yard or dock, etc.
MG Double Girder Gantry Crane Specification
Lifting Capacity 5~500t
Span Length 12~35m
Working Class A5, A6
Ambient Temperature -25~40℃
Semi-gantry crane is a small or middle scale gantry crane with one side of crane girder supported by one unilateral leg which can travel on the ground track, and the other side supported on the bracket track, which could save cost and space of the factory.
BMH Semi-gantry Crane Specification
Lifting Capacity: 2~10t
Span Length: 8~20m
Working Class: A3,A4
Ambient Temperature: -20~40℃
Crane Specifications PDF Download: BMH Semi-gantry Crane
Truss crane for material handling for windy environment with high safety, lower price and lighter weight. Truss crane, truss gantry crane, and single truss gantry crane are available now.
Truss Gantry Crane Specification
Lifting Capacity 2~500t
Span Length 12~35m
Working Class A5, A6
Ambient Temperature -25~40℃
Shipyard crane or ship building crane is a type of gantry crane used for ship building. Up to 700 ton shipyard gantry cranes can be designed for your application. Customized shipyard crane helps your ship building now!
Shipyard gantry crane specifications
Lifting Capacity : Customized
Span Length: Customized
Working Class: A5, A6
Ambient Temperature: -25~40℃
Types of jib cranes presentation
Wall mounted jib crane can be a tie-rod jib crane, which has a tie-rod mounted to the structure of your building, without taking any of your square feet of your plant. Wall mounted jib crane is widely in the places, such as, workshops, warehouses, docks, storage, ports, and assembly line, etc.
BX Wall Mounted Jib Crane Specification
Lifting Capacity 0.25~10t
Span Length 3~6m
Working Class A3
Ambient Temperature -25~40℃
Crane Specifications PDF Download: BX Wall Mounted Jib Crane
Pillar jib crane also called pillar mounted jib crane is a type of freestanding small and medium material handling equipment which is widely used in workshop, warehouse, dock, yard, storage and other places where the pillar can be installed, etc.
BZ Pillar Jib Crane Specification
Lifting Capacity 0.5~10t
Lifting Height 3~12m
Working Class A3
Ambient Temperature -25~40℃
Crane Specifications PDF Download: BZ Pillar Jib Crane
Wall travelling jib crane is a cost effective crane which travels along the rail mounted on the wall or other supported structure on elevated orbit of a multilayer assembly shop, making the full advantages of the working space.
BB Wall-travelling Jib Crane Specification
Lifting Capacity 0.5~10t
Lifting Height 3m~10m
Working Class A3
Ambient Temperature -25~40℃
Crane Specifications PDF Download: BB Wall-travelling Jib Crane
Port crane
RTG crane / Transtainer is a mobile rubber tyred gantry crane, often powered by diesel generator systems or other power supply equipment, which is widely used to handle and stack containers in yards, quysides, harbors, and freight stations, etc.
Rubber tyred gantry crane Specification
Lifting Capacity 20t~45t
Span Length 12m~18m
Working Class A6
Ambient Temperature -25~40
Single jib portal crane is the simplicity of portal crane, which is confirming with Harbor portal crane technical specifications, harbor portal crane safety specification, crane design standards.
Single Jib Portal Crane Specification
Lifting Capacity 10~35t
Span Length 5.5~16.5m
Working Class A6,A7
Ambient Temperature -25~40℃
Rail mounted container gantry cranes also called RMG cranes are a type of heavy crane, which is widely used to load and unload heavy items on rail transport yard, big container storage, docks, container yards and rail freight stations, transport and handling international ISO standard containers.
Rail Mounted Container Gantry Crane Specification
Lifting Capacity 25~65t
Span Length 15~35m
Working Class A6
Ambient Temperature -25~40℃
Quayside container cranes also called ship-to-shore cranes are one kind large quay container handling special equipment.
STS Quayside Container Crane Specification
Lifting Capacity 30~65t
Lifting Height 20~60m
Working Class A7,A8
Ambient Temperature -25~40℃
