European chain hoist：FEM low headroom chain hoist with 100 - 400mm headroom design

European low headroom chain hoist with capacity up to 50 tons with different low headroom designs of 100-150mm, 200mm, 350-400mm to meet you low clearance factory lifting. Check fem and European low headroom chain hoist now.

European electric chain hoist is a new type electric chain hoist compared with European wire rope hoists, to meet more needs of lifting requirements. The fem electric chain hoists can be grouped in European low headroom chain hoist, Super low low headroom chain hoist, Double hook european electric chain hoist, and wind power generation indusrial used electric chain hoist, and custom designed fem electric chain hoist, etc.

Low headroom chain hoist with FEM standards

The main parameters of European electric chain hoists are presented for your reference. If you need cutom designed fem electric chain hoists, please feel free to contact us. Leave us your requirments to the European chain hoists below, we will contact you in 24 hours.

Lifting capacity of FEM low headroom chain hoist

• The max lifting capacity can be 50 tons, the lifting height is unlimited.

Lifting height of FEM low headroom chain hoist

• Lifting height < 20m, the pocket of chain is plastic;
• Lifting height >20m, the pocket is steel. The pocket of chain is cloth.

Working duty of FEM low headroom chain hoist

• Max working grade is M8, continue working for 48 hours.

Headroom of FEM low headroom chain hoist

• Low headroom can reach 200mm (the distance from i-beam bottom to the hook center)
• Low headroom is 350-400mm
• Super low headroom chain hoist can reach 100-150mm.

Numbers of electric chain hoist hooks of FEM low headroom chain hoist

• 1 hoist hook is the most common design for the low headroom chain hoist
• 2 hoist hooks can be used to lift synchronously, with mechanical control, zero error.
• 3 and more than3 hoist hooks designs are also available with our custom electric chain hoists.

Electric chain hoist,European chain hoist, European low headroom chain hoist, fem hoist

FEM Standards for hoist and cranes

FEM standards for hoist and cranes of one of the European hoist and crane standards, such as, e.g. DIN STANDARDS (Germany), BSI STANDARDS (United Kingdom) BSI, CEN STANDARDS, etc.

The FEM(Federation Europeenne de la Manutention) has published standards specifically for material handling and lifting hoist and crane equipment. Some of the primary ones of the Federation Europeenne de la Manutention (FEM; website www.fem-eur.com) are:

• FEM 1.002 Illustrated Terminology of Heavy Lifting Equipment
• FEM 9.811 Rope and Chain Hoists – General Specifications
• FEM 9.511 Rules for the Design of Series Hoist and Crane Lifting Equipment - Classification of
• Mechanisms
• FEM 9.661 Rules for the design of Series Hoist and Crane Lifting Equipment - Dimensions and
• Design of Rope Reeving Components
• FEM 9.683 Selection of Hoist and Travel Motors
• FEM 9.852 Power Driven Series Hoist Mechanisms, Standardized Test
• Procedure for Verification of the Classification
• FEM 9.755 Measures for Achieving Safe Working Periods for Motorized Serial
• Hoist Units (S.W.P.)
• FEM 9.751 Power Driven Series Hoist Mechanisms, Safety
• FEM 9.901 Rules for the Design of Series Lifting Equipment and Cranes Equipped with Series Lifting Equipment

Comparison of European electric chain hoist and General electric chain hoist

European electric chain hoist is a new type electric chain hoist. Compared with the general electric chain hoist, it has many advantages in terms of hoist structure and application.In the following table, the main difference is showed for your reference.

How to select the FEM electric chain hoist

FEM hoist work shop for European chain hoist, European low headroom chain hoist manufacturing

In order to select the right European electric chain hoist, the following needs your attention.

Base of select European electric chain hoist

• Select the load spectrum type.
• Follow the load spectrum to the right, across the table and compare your average operating time per day value (t) to the limits in the table.
• Stop where your calculated value (t) is between the limits.
• Move down that same column to get your hoist group, duty factor, and maximum starts per hour.

Information needed for you to select FEM chain hoist

• Load Q = _____ kg
• Hoisting speed v = _____ m/min
• Average hoisting height H = _____ m
• Number of work cycles N = _____ /h
• Daily working time T = _____ h
• Load spectrum: _____

If you do not know about how to select the electric hoist, please feel free to leave us a message or email to sales@cranesdq.com. The reply of our electric hoist engineer will be given within 24 hours. Get your custom design fem electric chain hoist.
