Electric Chain Hoist

Electric chain hoist is a light and small lifting electric hoist together with overhead crane, gantry crane, jib crane for efficient material handling. Electric chain hoist is mainly consisted of motor, transmission mechanism and chain wheel, etc. Electric chain hoists from DQCRANES have the features of beautiful outlook, solid durability, and international technology, etc.

Types of standard electric chain hoists

Lifting capacity: 300kg~100 ton (300kg, 500kg, 1000kg, 2 ton, 3 ton, 5 ton, 10 ton, 20 ton, 25 ton, 30 ton, 50 ton, 60 ton, 100 ton), lifting height is 3~120m.

Dongqi offers types of electric chain hoists worked with types of chain cranes to meet your various lifting requirements, inculding trolley electric chain hoist and fixed type electric chain hoists, with different chain falls, etc. All Dongqi electric chain hoist can be supplied with various voltages, such as, 220v electric chain hoist, 240v electric chain hoist, 380v electric chain hoist, etc.

500kg -35 ton electric trolley chain hoist

500kg -30 ton manual trolley chain hoist

0.5-35 ton hook supesnion electric chain hoist

0.5 -30 ton low headroom electric chain hoist

Special designed electric chain hoist

The lifting capacity, lifting height, supply power voltage (380v/50hz/3 phase?) of the special designed electric chain hoists are needed to provide you cut to tail hoists.

Twin hook electric chain hoist

Explosion proof electric chain hoist

stage use electric chain hoist

Fem standard electric chain hoist

The electric chain hoists, fixed type electric chain hoists, and low headroom electric chain hoists are standard motorized chain hoist offering of Dongqi Hoist and Crane, which has stock can be delivered quickly. If you need custom desgined electric chain hoist, please feel free to contact us.

Electric Chain Hoist with Trolley

Electric trolley electric chain hoist for sale

Trolley hoist for sale at good price. Dongqi offers types of motorized trolley chain hoist and manual trolley electric chain hoists to meet your material handling solution at economical price. The inside gears of electric chain hoist are hot quenched which increases the wear resistance of the gear and toughness. The lifting capacity is 0.5 to 50 ton, and the working class is M3 or M4. The main parameters of electric chain hoist with trolley are as follow:

• Electric Chain Hoist Product Type: DHT, WBH
• Electric Chain Hoist Lifting Capacity: 0.5t~50t
• Electric Chain Hoist Lifting Height: 3~50m
• Electric Chain Hoist Working Class: M3,M4
• Ambient Temperature: -25~40℃

Capacity of electric trolley chain hoists

Dongqi Hoist and Crane offers types of electric trolley chain hoists designed with various chain falls from 2 chain falls, 3 chain falls up to 14 chain falls, with lifting capacity from 500kg chain hoist up to 50 tons. The custom designed electric trolley chain hoists are available. The most popular tonnage of the trolley electric chain hoist are 7.5 ton electric chain hoist, 10 ton electric chain hoist, 25 ton electric chain hoist, 30 ton electric chain hoist, etc. The pictures of the electric chain hoist and electric chain hoist drawing are shown in the following for your reference. If you need any trolley electric chain hoist, please leave us a message or email to sales@cranesdq.com.

500kg motorized trolley electric chain hoist	1 ton motorized trolley electric chain hoist	2 ton motorized trolley electric chain hoist	3 ton motorized trolley electric chain hoist
5 ton motorized trolley electric chain hoist	7.5 ton motorized trolley electric chain hoist	10 ton motorized trolley electric chain hoist	15 ton -20 ton motorized trolley electric chain hoist
25 ton motorized trolley electric chain hoist	30 ton motorized trolley electric chain hoist	500kg - 5 ton motorized trolley electric chain hoist	Custom made electric chain hoist

Manual trolley chain hoist

Manual trolley electric chain hoist is a type of light duty trolley hoist with lifting capacity from 500kg to 20 ton, with 1 chain fall design, 2 chain fall design, etc.

Manual trolley electric chain hoist for sale- Dongqi electric chain hoist

Main parameters of manual trolley chain hoist

• Maximum Lifting Weight:20t
• Maximum Lifting Height:100m
• Lift Speed: 6.8 m/min 5.4 m/min 2.7 m/min
• Certification: CE SGS ISO
• Type: Trolley type/ Fixed type
• Working class:M3
• Power supply: as your request
• Working temperature: -20℃~+40℃
• Chain Material: G80 Oil Black
• Protection class: IP 54
• Control Method: Pendant control/remote control
• Chain falls: according to the capacity

500kg - 20 ton manual trolley chain hoists deliver power and reliability for even your most heavy-duty lifting applications. The manual trolley chain hoist and drawing for your reference:

Hot capacity of manual trolley chain hoist

0.5 ton/500 kg manual trolley electric chain hoist

1 ton manual trolley electric chain hoist

2 ton manual trolley electric chain hoist

3 ton manual trolley electric chain hoist

Fixed type/ Hook suspension electric chain hoists

Fixed types electric chain hoist with lifting capacity from 300 kg- 50 ton with various types of fixed type chain hoist designs for sale at good price. Custom fixed type electric chain hoist is available. Get your electric chain hoist today.

Fixed type electric chain hoist - Dongqi electric chain hoist production workshop

Fixed type electric chain hoist, which is also called hook suspensin electric chain hoist is one type of electric hoist, used with overhead crane, gantry crane, and  jib crane  to be the most widely used material handling solutions. With the proper fixed electric chain hoist, we are able to lift and move the heavy objects and loads at the press of a button.
With proper fixed electric chain hoist, we are able to work with more efficiency, saving more energy, time and money in some extend. Also to make our working environment with high safety and saves life, living a more enjoyable life.

• Capacity ranges：300kgs -50tons
• Low noise: 81db
• Insulation grade: F class
• Electric chain hoist compact size and easy installation
• Working temperature: -40℃ – +40℃
• High quality G80 load chain

Hot capactiy of hook suspension electric chain hoists

Dongqi offers types of fixed electric chain hoist for your selection.Dongqi Hoist and Crane offers types of fixed type electric chain hoists designed with various chain falls from 2 chain falls, 3 chain falls up to 14 chain falls, with lifting capacity from 500kg up to 50 tons. The custom designed electric chain hoists are available. The 500kg- 5 ton fixed type eletric chain hoist, 10 ton fixed electric chain hoist, 35 ton fixed type electric chain hoist are presented for your reference.

500kg hook suspension electric chain hoist	1 ton hook suspension electric chain hoist	2 ton hook suspension electric chain hoist	3 ton hook suspension electric chain hoist
5 ton hook suspension electric chain hoist	7.5 ton hook suspension electric chain hoist	7.5ton hook suspension electric chain hoist	10 ton hook suspension electric chain hoist
25 ton hook suspension electric chain hoist	35 ton hook suspension electric chain hoist	1.5 ton hook suspension electric chain hoist	2.5 ton hook suspension electric chain hoist

If you want to know more about the hook suspension electric chain hoist, or need custom designed hook electric chain hoists, please feel free to contact us. WhatsApp/ Wechat: + 86 150 3617 7583.

Low headroom electric chain hoist

Low headroom electric chain hoists are designed for limite overheadroom workshop factorys to meet your lifitng requirements at affordable hoist prce. Custom designed electric chain hoist is available from Dongqi Hoist and Crane, please feel free to contact sales@cranesdq.com.

Low headroom electric chain hoist  for sale

Low headroom electric chain hoist with trolley for sale with capacity of 0.5 ton ~ 50 ton to save your headroom and workshop investment. 1 ton, 2 ton, 3 ton, 5 ton, 10 ton low headroom electric chain hoist with trolley for sale.

• Low headroom electric chain hoist capacity: 0.5 ~ 50t
• Lifting height of low headroom electric chain hoist: 3 ~ 130 m or customized
• Lifting speed: Single speed: 6.6 m/min; or customized；Variable frequency speed: 0.1 ~ 12.5 m/min; or customized
• Working class of low headroom electric chain hoist: M3 ~ M7
• Working temperature of low headroom electric chain hoist : -20 ~ 40 ℃
• Power supply of low headroom electric chain hoist: AC-3Phase-220//230380/400/415/440V-50/60Hz
• Control voltage of low headroom electric chain hoist: DC-36 / 48V

Hot capactiy of low headroom electric chain hoist

500 KG low headroom electric chain hoist	1 ton low headroom electric chain hoist	1.5 ton low headroom electric chain hoist	2 ton low headroom electric chain hoist
2.5 ton low headroom electric chain hoist	3 ton low headroom electric chain hoist	5 ton low headroom electric chain hoist	10 ton low headroom electric chain hoist

Applications of Electric Chain Hoist

DQCRANES electric chain hoists have a wide range of application, which can be used in various factory, storage, wind-power stations, logistics, ports, construction field, and other places or workshops, etc. Electric chain hoist also can be used to handle heavy objects for working or reparation. Electric chain hoist can be used together with monorail electric trolley for material handlings.

• Widely used in factory, storage, wind-power station, logistics, port and construction field.
• Used for lifting or loading. Or lifting heavy objects for working or reparation.
• It can be controlled by handle on ground or wire (no-wire) remote control.
• It can be suspended and fixed for using, or matched with monorail electric trolley (as following pictures.)

Features of Electric Chain Hoist

Electric chain hoist is designed with compact structure, small size, and light dead weight. DQCRANES electric chain hoist is reliable, easy operation, and wide application, etc.

1. On structure features.

• The body of electric chain hoist is made from high strength tensile shell or it can be die casting aluminum case based on your requirements. The molding process thin-walled precision manufacturing made the body small size, low weight, high strength.
• Separated speed adjusting system is adopted by our electric chain hoist. And the level 2 coaxial transmission speed gear mechanism uses long services oil bath lubrication system.
• Electric hoist powder metallurgy clutch is adopted for overload protection.
• The brake disc adopts dc magnetic field, braking torque, which is stable, rapid and low in noise, etc.

2. On lifting motor.

The lifting motor of electric chain hoist can work continuous for 30 minutes with full loading, high performance efficiency and has Grade B insulation.

3. On lifting chain.

• The lifting chain of electric chain hoist is made of low carbon steel alloy, which makes the chain more toughness, strong and wear-resisting, ensuring the safety during work, etc.
• The hardened chain surface of electric chain hoist can prevent core material and products from damage to ensure the high performance and long service life of hoist chain.
• Lifting chain can be extended based on customer’s requirement and enables the electric chain hoist more convenient, etc.
• Equipped with chain bag, the electric chain hoist is more orderly, tidy and beautiful. The chain bag contains antirust oil so that the lifting chain is kept from rusty and the working life is extended..

4. Double brake system

Electric chain hoist adopts two sets of braking systems, which reduces the possibility of brake failure and increases hoist safety and do benefit for heat radiation.

1) Electromagnetic brake.

The electromagnetic brake system is a new style brake, with the features of fast and forward direction. Asbestos brake lining has greatly extended the maintenance cycle. The brake system has been tested by above 22500 times.

2) Mechanical brake

The mechanical brake has high reliability. The mechanical braking and electromagnetic brake can coordinate with each other  to stop electric chain hoist at any time when necessary.

5. On gear.

• Standardbred chain electric hoists mainly adopt reliable helical gear, which can prolong service life by reducing the impact of meshing and vibration.
• The durability of gear is enhanced by the special design. And fine heat treated alloy steel is used to make the gear obtain the biggest strength.

6. Control handle with low voltage

• Electric chain hoist can be controlled by handle or ground or wire ( no-wire) remote control.
• The standard low-voltage on chain hoist handle is 24v-36v, which can effectively protect the operator from a shock damage.

Electric chain hoist parts

Trolley hoist for sale at good price. Dongqi offers types of electric trolley chain hoist and manual trolley chain hoists to meet your material handling solution at economical price. According to the power sources, Dongqi can offers you single electric chain hoist and three phase electric chain hoist with various voltages, 220v electric chain hoist, 240v electric chain hoist, 380v electric chain hoist,etc.

Electric chain fall hoist part: Shell	Shell It is made of light aluminum alloy shell, light but hard. The cooling fin is especially designed to ensure quick heat dissipation with the rate up to 40% and continuous service. The integral enclosed structure is applicable to places like chemical plant and electroplate factory. Contact to get electric chain hoist parts.
Electric chain fall hoist part:  Motor	Motor Manufactured by Dedong Motor factory, Special designed for the electric chain hoist.  Maintenance free. Insulation class F. Protection class IP55. Side magnetic breaking system inside.Contact to get electric chain hoist parts.
Electric chain fall hoist part:  Electtic trolley	Electric trolley High strength low alloy steel structure, with electric motor and high-wearing feature wheels, compact and easy to install.Contact to get electric chain hoist parts.
	Chain The chain shall adopt the imported ultra heat-treatable aluminum alloy chain. It can be safety used in power environments such as rain, sea water and chemicals .Contact to get electric chain hoist parts.
Electric chain fall hoist part: Chain Bag	Chain bag High wear resistance nylon material, store the lifting chain and prevent the chain from getting entangled with the main card or the chain when the chain is free to slide.Contact to get electric chain hoist parts.
Electric chain fall hoist part: Hook	Hook It is hot forging with perfect strength that is hard to break. The operation safety of the lower hook is ensured by its 360 degrees rotation and safety flap.Contact to get electric chain hoist parts.
Electric chain fall hoist part:  Electrics	Electrics Chint brand, China famous brand, Inverse phase sequence protecting device.Contact to get electric chain hoist parts.
Electric chain fall hoist part:  Limit Switch	Limit switch The limit switch device is installed where the weight is lifted on and off to make the motor to stop automatically so as to prohibit the chains from exceeding for safety.Contact to get electric chain hoist parts.
Electric chain fall hoist part: Pendant	Pendant with cable Yueqing Brand the best in china Master Controller with waterproof Push Button for UP, DOWN, Forward, Reverse, start& Emergency Stop. It is light and durable. Contact to get electric chain hoist parts.

Main types of electric hoists

Wire rope hoists

	Wire rope hoist for sale Wire rope hoist overview: 0.5 ton -32 ton rope hoist and wire hoist for sale from Dongqi, your wire rope hoist supplier. Dongqi offers types of wire rope hoists, such as, single/ double speed wire rope host, explosion proof wire rope hoist, metallurgy wire rope hoist, etc.
	Small electirc hoist for sale The mini electric hoist also named civil electric hoist is a light lifting equipment, with the lifting capacity of 0.2 to 1 ton. There are two types of mini electric hoists, the stationary and running types, which are widely used for various occasions. NOTE: Minimum Order of Quantity of Mimi/ Small electric hoist is 20 sets due to the low price. One set needed, please buy locally and we will not quote.
	Electric European wire rope hoist   The new serial of wire rope electric hoist is usually used on European crane / FEM Cranes with the features of environment-friendly, energy saving and cost-effective, ranking top among similar products. The lifting capacity of the European wire rope electric hoist is 1 to 80 tons and the working class is M5 and M6.

Electric chain hoist

	Electric trolly chain hoist Electric chain hoist is a light and small material handling equipment with the capacity of 0.5 ton to 35 ton. Dongqi electric chain hoist for sale at economical price now. Get your electric chain hoist today.
	Fixed type chain electric hoist Hook suspension hoists for sale. Dongqi 0.5 ton -35 ton electric chain hoists with suspension hook for sale at good price. Check suspension hook electric hoist specifications and parameters now.
	European electric chain hoist with fem standards European low headroom chain hoist with capacity of 1 t, 2 t, 3 ton, 5 ton, 10 ton up to 50 tons with different low headroom designs of 100-150mm, 200mm, 350-400mm to meet you low clearance factory lifting.

Projects of electric chain hoists for your references

	160 sets of 2 ton electric chain hoist & chain block for sale 2 ton hoists for sale Senegal. 2 ton electric chain hoists / electric chain fall hoists and chain blocks of 2 tons all together 160 sets are for sale Senegal. Check the specifications of the 2 ton hoists now.
	1.5 ton electric fall chain hoist for sale Australia 1.5 ton electric chain hoist packaged and delivered to Australia. Dongqi Group supply different tonnage electric chain hoist for Australia customer.
	Electric chain hoist and electric chain fall hoist Azerbaijan Electric chain hoist and chain fall for sale Azerbaijan. 11 pieces of electric chain hoists are ready to delivery to Azerbaijan. Dongqi offers types of electric chain fall hoistswith wide selection and application, good quality and price.
	5 ton electric chain hoist for Columbia 5 ton electric chain hoist for sale Columbia at good price. As an electric chain hoist supplier, Dongqi offers types of electric chain fall hoists, i.e. double hook electric chain hoist, low headroom electric chain hoist, and fixed type electric chain hoist, etc.
	7 ton electric hoist and electric chain hoist for sale 7 ton electric chain fall hoist for sale. Dongqi 7 ton hoist for sale. Dongqi offers types of 7 ton hoist, i.e., wire rope hoist and chain hoist, trolley hoist, etc.
	Electric chain hoist and Wire rope hoist for sale Philippines Electric chain hoist for sale Philippines. Dongqi 3 ton electric chain fall hoist and 10 wire rope hoist for sale Philippines case study for your reference.
	15 ton electric chain hoist with trolley for sale 15 ton electric chain hoist for sale.Dongqi15 ton electric chain hoistwith trolley is ready for delivery. The 15 ton motorized trolley chain fall hoist is one of the hot sale electric chain hoist at economical price.

Get your electric chain hoist price

In order to give you suitable electric chain hoist solution and specific electric hoist price promptly, please help our electric hoist engineer to confirm the following information as much as possible:

1. Types of hoist: fixed type or with trolley type electric chain hoist?
2. Capacity:
3. Height of Lift
4. Power supply: (3phase? Voltage? Hz?)
5. Quantity:
6. Operation: Through Pendant/Radio Remote
7. Indoor/Outdoor:
8. Application (What are you planning to lift)
9. Environment (Normal/ hazardous)
10. Location
11. Industry type: ( Eg: Auto, steel, sugar stone, etc.)
12. Rail Existing/New (Size in case of Existing)
13. Number of hoist:
14. Existing Structure/New Structure:

Our electric chain hoist portfolio can be modified and engineered to your exact requirements with a variety of options and features. Contact us to get more about our electric chain hoists that are available in numerous capacities, lifts, and configurations.
